AMD Ryzen™ 5 8400F Processor_x000D_ AMD Ryzen 5 8400F is the starting point for PC gaming processors._x000D_ _x000D_ _x000D_ GENERAL SPECIFICATIONS:_x000D_ Name AMD Ryzen™ 5 8400F_x000D_ Family Ryzen_x000D_ Series Ryzen 8000 Series_x000D_ Form Factor Desktops_x000D_ AMD PRO Technologies No_x000D_ Former Codename Phoenix_x000D_ Architecture Zen 4_x000D_ # of CPU Cores 6_x000D_ Multithreading (SMT) Yes_x000D_ # of Threads 12_x000D_ Max. Boost Clock Up to 4.7 GHz_x000D_ Base Clock 4.2 GHz_x000D_ L2 Cache 6 MB_x000D_ L3 Cache 16 MB_x000D_ Default TDP 65W_x000D_ AMD Configurable TDP (cTDP) 45-65W_x000D_ Processor Technology for CPU Cores TSMC 4nm FinFET_x000D_ CPU Compute Die (CCD) Size 178mm2_x000D_ Package Die Count 1_x000D_ Unlocked for Overclocking Yes_x000D_ AMD EXPO™ Memory Overclocking Technology Yes_x000D_ Precision Boost Overdrive Yes_x000D_ Curve Optimizer Voltage Offsets Yes_x000D_ AMD Ryzen™ Master Support Yes_x000D_ CPU Socket AM5_x000D_ CPU Boost Technology Precision Boost 2_x000D_ Instruction Set x86-64_x000D_ Supported Extensions AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSSE3 , SSE4.1 , SSE4.2 , SSE4A , x86-64_x000D_ Max. Opera
